F1201-4120001054:多路阀(331005)-41 Control valve assembly(331005)

1 安全阀XDY32G01-00A-16 Valve 4120001133026 Y 1
2 螺栓D32A-21 SCREW 4120001054231 Y 5
3 垫圈GB93-87 12 WASHER 4120001054234 Y 5
4 辅助阀杆D32A-11a-00 VALVE ROD 4120001054224 Y 1
5 弹簧座D32-6 SPRING SEAT 4120001054214 Y 6
6 阀杆接头D32-21 JOINT 4120005199015 Y 3
7 弹簧D32-7 SPRING 4120001054215 Y 3
8 弹 簧GD32-8 SPRING 4120000413005 Y 3
9 垫圈GB97.1-12-300HV WASHER 4015000313 Y 3
10 螺栓M12×20 GB30-76 SCREW 4120005199017 Y 3
11 O型圈GB1235-76 45X3.1 O-RING 4120001054232 Y 1
12 螺塞D32-3 PLUG 4120001054222 Y 6
13 O形圈GB1235-202.4 O-RING 4030000011 GB1235-202.4 Y 6
14 转斗阀杆D32-12w VALVE ROD 4120000413007 Y 1
15 动臂阀杆D32-2w VALVE ROD 4120000413006 Y 1
16 螺栓GB5782-M10100-8.8 SCREW 4011000933 Y 6 17 垫圈GB97.1-10-300HV WASHER 4015000322 (4015000162) N 12 18 端盖D32-5a COVER 4120001054243 Y 3 19 O形圈GB1235-603.1 O-RING 4030000638 Y 3
20 低压过载阀Y20G01-00A-12 Valve 4120001133028 Y 1
21 高压过载阀D32A.1-00b-18 Valve 4120001133027 Y 1
22 补油阀D32-15 VALVE 4120001054016 Y 1
23 弹簧D32-14 SPRING 4120001054209 Y 1
24 O形圈GB1235-503.1 O-RING 4030000760 Y 1 25 补油阀盖D32-13a VALVE COVER 4120000413004 Y 1 26 单向阀D32-17 CHECK VALVE 4120001054203 Y 4 27 弹簧D32-16 SPRING 4120001054204 Y 4 28 O形圈GB1235-443.5 O-RING 4030000706 Y 4
29 单向阀盖D32-19 VALVE COVER 4120001054206 Y 4
30 端盖D32-1W VALVE COVER 4120001054238 Y 3
31 螺栓M1025(GB5782) SCREW 2835000007030 N 6 32 O形圈GB1235-553.1 O-RING 4030000707 GB1235-553.1 Y 1 33 O形圈GB1235-353.5 O-RING 4030000149 GB1235-353.5 Y 1 34 O型圈GB1235-76 45X3.1 O-RING 4120001054232 Y 1 35 堵头D32A-20 PLUG 4120001054226 Y 1 36 O形圈GB1235-222.4 O-RING 4030000012 GB1235-222.4 Y 2 37 O形圈GB1235-283.1 O-RING 4030000981 Y 2
38 堵头D32A-23 PLUG 4120001054229 Y 2
39 O型圈GB1235-76 50X3.5 O-RING 4120001054237 Y 3
