J2200-2922001995.S1b:行车制动总成-70 Travel brake system

1 螺栓GB16674.1-M830flZnyc-8.8-480 SCREW 4011001301 Y 2 2 螺栓GB16674.1-M812flZnyc-8.8-480 SCREW 4011001313 Y 2
3 桥油管 BRAKE PIPE 29220020451 Y 4
4 后桥右油管 BRAKE PIPE 29220020171 Y 1
5 软管LGB128-405162 HOSE 4041001833 Y 1
6 至前桥制动油管 HOSE ASSEMBLY 29220013951 Y 1
7 扎丝LG13-ZS4250 CABLE TIE 4190000020 LG13-ZS4250 Y 8
8 管夹 CLAMP 29030000041 ZL50G.6.53 Y 1
9 橡胶套 RUBBER SLEEVE 29270007792 Y 1
10 直接头 NIPPLE 29220010271 Y 2
11 螺栓GB16674.1-M1020flZnyc-8.8-480 SCREW 4011001294 Y 2 12 螺栓GB16674.1-M835flZnyc-8.8-480 SCREW 4011001277 Y 6
13 串联踏板阀06-466-435 CONTROL VALVE 4120005158 Y 1
14 护罩底板 PROTECTING COVER 29220018831 Y 1
15 接头GE12L9/16UNFOMDA3C NIPPLE 4190000147 GE12L9/16UNFOMDA3C Y 6
16 接头EW12LOMDA3C NIPPLE 4190000141 Y 10
17 管夹 CLAMP 26370001921 N 1
-4041002377
18 管接头 NIPPLE 29220009011 Y 4
19 前桥右油管 BRAKE PIPE 29220020131 Y 1
20 O形圈 O-RING 4030000552 Y 16
21 接头块 BLOCK 29220009021 Y 8
22 制动器管接头 NIPPLE 29220001251 Y 4
23 固定板 ANCHOR PLATE 29220011131 Y 1
24 三通接头 NIPPLE 29220015381 Y 2
25 前桥左油管 BRAKE PIPE 29220020111 Y 1
26 过渡接头EW10LOMDA3C NIPPLE 4190000176 EW10LOMDA3C Y 1
27 螺栓3/8-16UNC SCREW 29220018821 Y 2
28 充液阀支架 BRACKET 29220013971 Y 1
29 双路充液阀06-463-424 CHECK VALVE 4120002767 Y 1
30 垫圈GB97.1-10flZnyc-300HV-480 WASHER 4015000433 Y 10
31 螺栓GB5783-M812flZnyc-8.8-480 SCREW 4011001314 Y 4 32 螺母GB6170-M10flZnyc-8-480 NUT 4013000370 Y 8 33 护罩盖板 PROTECTING COVER 29220018851 Y 1 34 橡胶垫 RUBBER MAT 29220011461 Y 1 35 U形螺栓 U-BOLT 29220010301 Y 2 36 垫圈GB97.1-8flZnyc-300HV-480 WASHER 4015000430 Y 8 37 螺母GB889.1-M8flZnyc-8-480 NUT 4013000384 Y 4 38 螺栓GB16674.1-M845flZnyc-8.8-480 SCREW 4011001305 Y 2
39 接头块 BLOCK 29220009221 Y 1
40 制动尾灯压力开关 SWITCH 4120004340 Y 1
41 后桥左油管 BRAKE PIPE 29220020151 Y 1
42 软管LGB128-005040 HOSE ASSEMBLY 4041001765 Y 1
43 软管LGB128-005043 HOSE ASSEMBLY 4041001986 Y 1
44 软管LGB128-405100 HOSE 4041001953 Y 1
45 三通接头EL12LOMDA3C THREE-WAY NIPPLE 4190000143 EL12LOMDA3C Y 3
46 胶管 HOSE ASSEMBLY 29220015361 Y 2
47 软管LGB124-005128 HOSE ASSEMBLY 4041002318 Y 2
48 至后桥软管 HOSE ASSEMBLY 29220018811 Y 1
49 软管LGB128-404100 HOSE 4041000884 Y 1
50 缓冲套 RUBBER SLEEVE 29220010311 Y 2
51 蓄能器NXQ-A-1.6/31.5-L-Y ACCUMULATOR 4120004659 Y 2
52 接头GE12L3/4UNFOMDA3C NIPPLE 4190000149 GE12L3/4UNFOMDA3C Y 3
53 直接头1-1/16-12UN-M18 NIPPLE 29220017621 Y 1
54 螺栓GB5783-M1025flZnyc-8.8-480 SCREW 4011001248 Y 4 55 压力油过滤器PLF-H11010 HYDRAULIC FLUID FILTER 4120004417 Y 1
56 变径接头 NIPPLE 29220012581 Y 2
57 O形圈GB3452.1-43.72.65G O-RING 4030000894 Y 2 58 软管LGB125-005122 HOSE ASSEMBLY 4041001976 Y 1 59 直接头LGB120-01818 NIPPLE 4041000766 Y 2 60 O形圈LGB168-11524 O-RING 4041000768 Y 2 61 螺栓GB5783-M1225flZnyc-8.8-480 SCREW 4011001241 Y 2
62 垫圈GB97.1-12flZnyc-300HV-480 WASHER 4015000428 Y 2
63 动力切断开关JK931-01DL ROCKER SWITCH 4130000504 Y 1
64 压力油过滤器滤芯LH0110D010BN/HC FILTER INSERT 4120004417001 Y 1
65 过渡板B PLATE 29220015341 Y 1
66 过渡板A PLATE 29220015331 Y 1
67 螺栓GB16674.1-M8*20flZnyc-8.8-480 SCREW 4011001296 Y 4
68 卡子胶条LGB320-S400 Sealing strip 4043000951 Y 1
