A19-4110001592:配气机构 G003505001-15 Spare parts kit

1 进气门612600050073 INLET VALVE 4110000556089 Y 6
2 进气门弹簧下座614050017 SPRING SEAT 4110000556090 Y 6
3 气门内弹簧61500050001 VALVE SPRING 4110000556169 Y 12
4 气门外弹簧61500050002 VALVE SPRING 4110000556173 Y 12
5 气门弹簧上座61500050109 SPRING SEAT 4110000556163 Y 12
6 气门锁夹61500050025 COLLET 4110000556170 Y 24
7 气门帽61500050105 VALVE CAP 4110000556168 Y 12
8 气门挺柱61500050032 TAPPET 4110000556171 Y 12
9 推杆 612600050214 PUSH ROD 4110001592045 612600050214 Y 12
10 气门间隙调整螺钉614050010 SCREW 4110000556166 Y 6
11 进气门摇臂614050048 ROCKER ARM 4110000113004 N 6
12 气门间隙调整螺母2130050065 NUT 4110000556167 Y 6
13 进气门摇臂总成612600050177 ROCKER ARM 4110000924018 612600050177 Y 6
14 气门摇臂座614050119 SEAT 4110000113006 Y 6
15 六角头螺栓90003802655 SCREW 4110000924101 Y 24
16 排气门摇臂614050049 ROCKER ARM 4110000113005 N 6
17 排气门摇臂总成612600050178 ROCKER ARM 4110000924019 612600050178 Y 1
18 排气门612600050025 EXHAUST VALVE 4110000556145 Y 6
19 凸轮轴 612600050024 Camshaft 4110001592046 612600050024 N 1
20 圆柱销90003901409 PIN 4110001015122 Y 1
21 凸轮轴正时齿轮 61800050144 GEAR 4110001592047 61800050144 Y 1
22 六角头螺栓612600050145S SCREW 4110000556116 Y 4
23 中间齿轮 61800050014 Gear 4110001592048 61800050014 N 1
24 衬套61560050051 BEARING BUSHING 4110000924100 N 1
25 中间齿轮总成 61800050098 GEAR 4110001592049 61800050098 Y 1
26 六角头螺栓90003802399 SCREW 4110000924098 Y 2
27 凸轮轴止推片614050133 THRUST WASHER 4110000556198 Y 1
28 中间齿轮轴61560050044 SHAFT 4110000556244 Y 1
29 轴61560050058 SHAFT 4110000556248 Y 1
30 垫片61560050045 WASHER 4110000556033 Y 1
31 六角头螺栓61560050059S SCREW 4110000556120 Y 4
32 凸轮轴总成 612600050087 CAMSHAFT 4110001592050 612600050087 Y 1
