E0716-4120004308:制动钳（360301）-25 Brakecaliper(360301)

1 钳体FY10756.00001 DRUM SHELL 4120004541008 Y 1
2 盖板FY10756.00002 COVER PLATE 4120004541004 Y 1
3 Y形密封圈FY10756.00004 SEALING RING 4120004308002 Y 6
-4120004308007
4 防尘罩FY10754B.00005 RUBBER STOP 4120004541014 Y 6
5 摩擦片总成FY10756.01000 FRICTION PLATE 4120004541015 Y 2
6 活塞FY10754A.00003 BRAKE PISTON 4120004541012 Y 6
7 螺栓GB5783-M1035EpZn-8.8 BOLT 4011000085 GB5783-M1035EpZn-8.8 Y 4
8 螺母M10（GB6170-86） NUT 2808000112015 N 4
9 支销FY10756.00003 PIN 4120004541009 Y 4
10 垫圈GB93-87 12 WASHER 4120001054234 Y 8
11 堵塞FY10754B.00006 PLASTIC PLUG 4120004541001 N 1
12 组合垫圈14JB982-77 Washer 4110002301003 N 2
13 放气嘴座FY10754M.00003 VALVE SEAT 4120004541006 Y 2
14 放气嘴 NIPPLE 4120001740 Y 2
15 标牌FY10754M.00005 Name plate 4120004308003 N 1
16 O型密封圈80X3.1GB1235-76 O-ring 4120004308004 Y 3
-4120004308006
17 螺栓GB5783-M1435EpZn-10.9 SCREW 4011000540 GB5783-M1435EpZn-10.9 Y 2
18 垫圈GB93-14-65Mn SPRING WASHER 4015000027 GB93-14-65Mn Y 2
19 螺栓GB5783-M1235EpZn-10.9 BOLT 4011000596 GB5783-M1235EpZn-10.9 Y 8
