F10-4120002672:动臂油缸（3713CH）-41 Lifting cylinder assembly(3713CH)

1 活塞杆241000202 piston rod 4120002672001 N 1
2 耳环座249000129 SEAT 4120003814003 Y 1
3 密封件包 SEALING RING KIT 4120002672003 Y 1
4 密封件包 SEALING RING KIT 4120002672003 Y 1
5 缸盖243000075 cover 4120003814005 N 1
6 密封件包 SEALING RING KIT 4120002672003 Y 1
7 密封件包 SEALING RING KIT 4120002672003 Y 1
8 密封件包 SEALING RING KIT 4120002672003 Y 1
9 密封件包 SEALING RING KIT 4120002672003 Y 1
10 密封件包 SEALING RING KIT 4120002672003 Y 1
11 密封件包 SEALING RING KIT 4120002672003 Y 1
12 缸体242000096 cylinder 4120002672012 N 1
13 密封件包 SEALING RING KIT 4120002672003 Y 1
14 活塞244000077 PISTON 4120003814008 Y 1
15 密封件包 SEALING RING KIT 4120002672003 Y 2
16 密封件包 SEALING RING KIT 4120002672003 Y 2
17 密封件包 SEALING RING KIT 4120002672003 Y 1
18 螺钉GB70.1-M825-8.8 SCREW 4014000171 Y 1 19 钢球GB308-5-GCr6 BALL 4090000168 Y 1 20 螺钉GB70.1-M1660-12.9 SCREW 4014000319 Y 16
21 垫圈GB93-16-65Mn SPRING WASHER 4015000098 GB93-16-65Mn Y 16
